FACTORY INFRASTRUCHERS

At V-MAK Engineering Solutions, we take pride in our world-class 22,000 sq. ft manufacturing facility, purpose-built to ensure precision, productivity, and quality across every project. Our modern infrastructure is designed to support high-volume production, custom engineering, and on-time delivery all with a strong focus on customer satisfaction.

AVAILABLE OVERHEAD CRANE FACILITY crane

" 1 crane with a capacity of two tons "

MACHINE SHOP FACILITIES

To ensure high quality and precision, our machine shop is equipped with a comprehensive range of calibrated measuring tools and gauges, including micrometers, vernier calipers, vernier height gauges, level gauges, and more.

For fabrication requirements, we use Power Master brand tube-sheet hole reaming and groove tools. The shop is also equipped with two heavy-duty lathe machines and two radial drilling machines. A level platform is in place to maintain dimensional accuracy and alignment.

The Power Master tube expansion system, featuring a torque controller, ensures proper and secure expansion of tubes into the tube sheet.

MANUFACTURING FACILITY

Welding machines at our fabrication shop are capable of doing ARC, TIG, and MIG welding. The details of the welding machine are as follows:

  • Mig Welding 400 Amps Capacity: 4Nos
  • Tig Welding 300 Amp Capacity: 2 Nos
  • Arc Welding: 5 Nos
  • Automatic PUG Cutting: 1 No.
  • laser cutting – 1No
  • Sheet Bending – 1No
  • Sheet Rolling -1No
  • Air compressors for Painting
  • Gas cutting machines.

According to the ASME requirements for GTAW/SMAW welding, our welders are qualified.

DESIGN DIVISION

Our design team is made up of skilled Drafts people and design engineers who use the newest technologies and design software. Our designs conform to ASME Code, TEMA Standards, and Good Engineering Practice With the newest design software and technologies, Our design team is made up of seasoned design engineers and draftsmen. According to our designs, Good Engineering Practices, ASME Code, and TEMA Standards In accordance with client needs, we are able to design provider of Auto Cad 2D and 3D Drawings, Mechanical Design, and Thermal Design.

LASER CUTTING MACHINE

Specifications

Laser power 1500W
Laser wavelength 1060-1080 nm
Plate cutting size 3000(L)*1500(W) mm
Z-axis path 120 mm
Machine tolerance± 0.02 mm/m
Repetition tolerances ± 0.03mm
X,Y-axis location accuracy ≤±0.02mm
X,Y-axis repeat location accuracy≤±0.02mm
X,Y-axis idle moving speed120 m/min
Acceleration rate1.2 G
Machine dimension 4470mm*2123mm*1800mm
Machine total weight 5.0T

CNC BENDING MACHINE

Specifications

ItemParameter ValuesUnitRe
Nominal Pressure1000KN
Worktable Length2500mm
Distance Between Columns2000 mm
Slide Stroke200 mm
Max Opening Height460 mm
Depth of Throat400 mm
Driving Speed120mm/s
Working Speed9mm/s
Return Rate95mm/s
Motor Power11kW
Oil Pump25ml/r
CNC Control System DA53T—
Control Axis4+1 axisY1, Y2, X, R + V

LASER ENGRAVING MACHINE

Specifications

ParameterRemarks
Laser Power20 W (Other laser power sources are available)
Laser Wavelength 1064 nm
Marking Range110 x 110 mm (Other sizes are available)
Marking Speed 0–8000 mm/s (12000 mm/s also available)
Minimum Character 0.2 mm
Minimum Line Width 0.035 mm
Repeat Accuracy±0.01 mm
Marking Depth1.2 mm (Penetration depends on the material)
Beam QualityM² < 1.8
Cooling SystemAir cooling
Supporting FormatVector file formats (ai, plt, dxf, jpc, svg, nc.g, bot, dst)
Power Supply220V / 50Hz AC

LASER WELDING MACINE

Specifications

FeatureTechnical Data
Laser Power3000W
Center Wavelength1064nm ±5
Modulation Frequency0–5000 Hz
Fiber Cable Length10 m
Power Adjustable Range10%–100%
Cooling MethodWater Cooling
Auxiliary GasN₂ / Argon
Rated Power415V AC, 50/60 Hz
Gross Weight200 kg (GW)
Packing Dimension1165 × 710 × 1680 mm

STRENGTH OF MANPOWER

10

No of Skilled workers

6

Untrained Workers

8

Staff in the Office
